ASTM A333 Qeb 6 Kev Ntsuas Rated Yeeb Nkab

ASTM A333 Qib 6 Tubing Siab ntsuas

ASTM A333 Qib 6 Tubing Siab thiab Kub

ASTM A333 Qib 6 - Carbon Steel Yeeb Nkab Siab (psig) thiab kub (degrees F) kev ntsuas rau A-53 B thiab A-106 B, A333, Carbon Steel Pipe A334 thiab API 5L - kub ntawm 100 degree F thiab 700 degree F

Muab xam qhov tseem ceeb (saib cov lus hauv qab no) raws li Table K-1 ntawm ASME B31.3-2002 rau Standard Plain End Seamless Carbon Steel Pipe, Specification No. A{{3} }B, A{ {4}}B, thiab API 5L. A-53B, A-106B, A333, A334 thiab API 5L. Qhov kub ntawm 100 ° F txog 700 ° F.

SIZE (IN)	EXTERNAL DIAMETER (IN)	Phab ntsa tuab (IN)	SIJ HAWM DIAMETER (IN)	Txoj Haujlwm	TUB ROG)
					100	200	300	400	500	600	650	700
					Tso zis hluav taws xob (PSI)
					23300	21300	20700	20000	18900	17300	16900	16800
					MAXIMUM NYIAJ NYIAJ PAB (PSI)
1/2	0.84	0.109	0.622	401)	6747	6168	5994	5792	5473	5010	4894	4865
	0.84	0.147	0.546	802)	9483	8669	8424	8140	7692	7041	6878	6837
	0.84	0.188	0.464	160	12704	11614	11287	10905	10305	9433	9215	9160
	0.84	0.294	0.252		22653	20708	20125	19444	18375	16819	16431	16333
3/4	1.05	0.113	0.824	40	5487	5016	4875	4710	4451	4074	3980	3957
	1.05	0.154	0.742	80	7743	7079	6879	6647	6281	5749	5616	5583
	1.05	0.219	0.612	160	11666	10665	10364	10014	9463	8662	8462	8412
	1.05	0.308	0.434		17861	16328	15868	15331	14488	13261	12955	12878
1	1.315	0.133	1.049	40	5128	4688	4556	4402	4160	3808	3720	3698
	1.315	0.179	0.957	80	7118	6507	6324	6110	5774	5285	5163	5133
	1.315	0.25	0.815	160	10448	9552	9283	8969	8475	7758	7578	7534
	1.315	0.358	0.599		16219	14827	14409	13922	13156	12042	11764	11694
1 1/4	1.66	0.14	1.38	40	4214	3853	3744	3618	3419	3129	3057	3039
	1.66	0.191	1.278	80	5905	5398	5246	5069	4790	4385	4283	4258
	1.66	0.25	1.16	160	7979	7295	7089	6849	6473	5925	5788	5753
	1.66	0.382	0.896		13143	12015	11677	11282	10661	9759	9533	9477
1 1/2	1.9	0.145	1.61	40	3788	3462	3365	3251	3072	2812	2747	2731
	1.9	0.2	1.5	80	5356	4897	4759	4598	4345	3977	3885	3862
	1.9	0.281	1.338	160	7187	7146	6944	6710	6341	5804	5670	5636
	1.9	0.4	1.1		11797	10785	10481	10127	9570	8759	8557	8506
2	2.375	0.109	2.157	10	2220	2030	1972	1906	1801	1648	1610	1601
	2.375	0.154	2.067	40	3187	2913	2831	2736	2585	2366	2312	2298
	2.375	0.218	1.939	80	4616	4220	4101	3963	3745	3428	3348	3329
	2.375	0.25	1.875		5356	4897	4759	4598	4345	3977	3885	3862
	2.375	0.281	1.813		6090	5567	5410	5227	4940	4522	4417	4391
	2.375	0.344	1.687	160	7634	6979	6782	6553	6193	5668	5537	5505
	2.375	0.436	1.503		10027	9167	8908	8607	8134	7445	7273	7230
2 1/2	2.875	0.12	2.635	10	2012	1840	1788	1727	1632	1494	1460	1451
	2.875	0.203	2.469	40	3487	3188	3098	2993	2829	2589	2529	2514
	2.875	0.216	2.443		3725	3405	3309	3197	3022	2766	2702	2686
	2.875	0.25	2.375		4355	3981	3869	3738	3533	3234	3159	3140
	2.875	0.276	2.323	80	4846	4430	4305	4159	3931	3598	3515	3494
	2.875	0.375	2.125	160	6786	6204	6029	5825	5505	5039	4922	4893
	2.875	0.552	1.771		10571	9664	9391	9074	8575	7849	7667	7622
3	3.5	0.12	3.26		1643	1502	1459	1410	1333	1220	1192	1184
	3.5	0.156	3.188		2154	1969	1913	1849	1747	1599	1562	1553
	3.5	0.172	3.156		2384	2179	2118	2046	1934	1770	1729	1719
	3.5	0.188	3.124		2615	2391	2324	2245	2122	1942	1897	1886
	3.5	0.216	3.068	40	3025	2766	2688	2597	2454	2246	2194	2181
	3.5	0.25	3		3530	3227	3136	3030	2864	2621	2561	2545
	3.5	0.281	2.938		3998	3655	3552	3432	3243	2969	2900	2883
	3.5	0.3	2.9	80	4288	3920	3810	3681	3479	3184	3110	3092
	3.5	0.438	2.624	160	6480	5924	5757	5563	5257	4812	4700	4673
	3.5	0.6	2.3		9258	8464	8225	7947	7510	6874	6715	6675
3 1/2	4	0.12	3.76	10	1432	1309	1273	1230	1162	1064	1039	1033
	4	0.226	3.548	140	2758	2521	2450	2367	2237	2047	2000	1988
	4	0.25	3.5		3066	2803	2724	2632	2487	2276	2224	2211
	4	0.281	3.438		3469	3171	3082	2977	2814	2575	2516	2501
	4	0.318	3.364	80	3956	3617	3515	3396	3209	2938	2870	2853
	4	0.636	2..728 ib		8489	7761	7542	7287	6886	6303	6157	6121
4	4.5	0.12	4.26	10	1270	1161	1128	1090	1030	943	921	916
	4.5	0.156	4.188		1662	1519	1476	1426	1348	1234	1205	1198
	4.5	0.188	4.124		2014	1841	1789	1729	1634	1495	1461	1452
	4.5	0.203	4.094		2181	1994	1938	1872	1769	1619	1582	1572
	4.5	0.219	4.062		2360	2157	2096	2026	1914	1752	1712	1701
	4.5	0.237	4.026	40	2562	2342	2276	2199	2078	1902	1858	1847
	4.5	0.25	4		2709	2477	2407	2326	2198	2012	1965	1953
	4.5	0.281	3.938	60	3063	2800	2721	2629	2485	2274	2222	2208
	4.5	0.312	3.876		3421	3127	3039	2936	2775	2540	2481	2466
	4.5	0.337	3.826	80	3712	3394	3298	3186	3011	2756	2693	2677
	4.5	0.438	3.624	120	4919	4497	4370	4222	3990	3652	3568	3547
	4.5	0.531	3.438	160	6072	5551	5394	5212	4925	4508	4404	4378
	4.5	0.674	3.152		7930	7249	7045	6807	6432	5888	5752	5718
5	5.563	0.188	5.187		1619	1480	1438	1389	1313	1202	1174	1167
	5.563	0.219	5.125		1894	1732	1683	1626	1536	1406	1374	1366
	5.563	0.258	5.047	40	2244	2052	1994	1927	1821	1667	1628	1618
	5.563	0.281	5.001		2453	2242	2179	2106	1990	1821	1779	1769
	5.563	0.312	4.939		2736	2501	2431	2349	2220	2032	1985	1973
	5.563	0.344	4.875		3032	2771	2693	2602	2459	2251	2199	2186
	5.563	0.375	4.813	80	3320	3035	2950	2850	2693	2465	2408	2394
	5.563	0.5	4.563	120	4513	4126	4009	3874	3661	3351	3273	3254
	5.563	0.625	4.313	160	5753	5259	5111	4938	4666	4271	4172	4148
	5.563	0.75	4.063		7042	6438	6256	6045	5712	5229	5108	5078

ASTM A333 Qib 6 PIPE SIZE CHART

ASTM A333 Qib 6 Pipe Dimensions, NB Loj Teem sijhawm

NB	SIZE	RE	40 S	5S	10S	S10	S20	S40	S60	XS/80S	S80	S100	S120	S140	S160	XXS
mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
	1/8 "	10.29			1.2			1.73			2.41
	1/4 "	13.72			1.7			2.24			3.02
	3/8 "	17.15			1.7			2.31			3.2
15	1/2 "	21.34	2.8	1.7	2.1			2.77		3.73	3.73				4.78	7.47
20	3/4 "	26.67	2.9	1.7	2.1			2.87		3.91	3.91				5.56	7.82
25	1"	33.4	3.4	1.7	2.8			3.38		4.55	4.55				6.35	9.09
32	1 1/4"	42.16	3.6	1.7	2.8			3.56		4.85	4.85				6.35	9.7
40	1 1/2"	48.26	3.7	1.7	2.8			3.68		5.08	5.08				7.14	10.2
50	2"	60.33	3.9	1.7	2.8			3.91		5.54	5.54				9.74	11.1
65	2 1/2"	73.03	5.2	2.1	3.1			5.16		7.01	7.01				9.53	14
80	3"	88.9	5.5	2.1	3.1			5.49		7.62	7.62				11.1	15.2
90	3 1/2"	101.6	5.7	2.1	3.1			5.74		8.08	8.08
100	4 "	114.3	6	2.1	3.1			6.02		8.56	8.56		11.1		13.5	17.1
125	5 "	141.3	6.6	2.8	3.4			6.55		9.53	9.53		12.7		15.9	19.1
150	6 "	168.3	7.1	2.8	3.4			7.11		10.97	11		14.3		18.3	22
200	8 "	219.1	8.2	2.8	3.8		6.4	8.18	10.3	12.7	12.7	15.1	19.3	20.6	23	22.2
250	10"	273.1	9.3	3.4	4.2		6.4	9.27	12.7	12.7	15.1	19.3	21.4	25.4	28.6	25.4
300	12 "	323.9	9.5	4	4.6		6.4	10.3	14.3	12.7	17.5	21.4	25.4	28.6	33.3	25.4
350	14 "	355.6	9.5	4	4.8	6.4	7.9	11.1	15.1	12.7	19.1	23.8	27.8	31.8	35.7
400	16 "	406.4	9.5	4.2	4.8	6.4	7.9	12.7	16.7	12.7	21.4	26.2	31	36.5	40.5
450	18 "	457.2	9.5	4.2	4.8	6.4	7.9	14.3	19.1	12.7	23.8	29.4	34.9	39.7	45.2
500	nees nkaum"	508	9.5	4.8	5.5	6.4	9.5	15.1	20.6	12.7	26.2	32.5	38.1	44.5	50
550	22 "	558.8	9.5	4.8	5.5	6.4	9.5		22.2	12.7	28.6	34.9	41.3	47.6	54
600	24"	609.6	9.5	5.5	6.4	6.4	9.5	17.5	24.6	12.7	31	38.9	46	52.4	59.5
650	26 "	660.4	9.5			7.9	13			12.7
700	28 "	711.2	9.5			7.9	13			12.7
750	30 "	762	9.5	6.4	7.9	7.9	13			12.7
800	32 "	812.8	9.5			7.9	13	17.5		12.7
850	3.4 "	863.6	9.5			7.9	13	17.5		12.7
900	36 "	914.4	9.5			7.9	13	19.1		12.7

ASTM A333 QIB 6 PIPE WEIGHT

ASTM A333 Qib 6 Yeeb Nkab Dimensions thiab Nyhav Tshooj Modulus thiab Gallons Ib Daim Taw Taw Muaj Peev Xwm

N.P.S. Size	cev OD	Phab ntsa thickness	Pipe ID	hnyav ib ko taw	Standard rau XXHY	Teem caij Tube #	ntu module	nkas loos muaj peev xwm ib tug linear ko taw
1/2	0.84	0.109	0.622	0.85	STD	40	ib .0407	ib .0158
		0.147	0.546	1.09	XHY	80	0478 ib	.0122
		0.188	0.464	1.31		160	ib .0528	ib .0088
		0.294	0.252	1.72	XXHY		0577 ib	ib .0026
3/4	1.05	0.113	0.824	1.13	STD	40	.0705 ib	ib .0277
		0.154	0.742	1.48	XHY	80	ib .0853	ib .0225
		0.219	0.612	1.95		160	.1006	ib .0153
		0.308	0.434	2.44	XXHY		.1103 ib	ib .0077
1	1.315	0.133	1.049	1.68	STD	40	.1328 ib	ib .0449
		0.179	0.957	2.17	XHY	80	.1606 ib	ib .0374
		0.250	0.815	2.85		160	.1904 ib	ib .0271
		0.358	0.599	3.66	XXHY		.2136 ib	ib .0146
1 1/4	1.66	0.140	1.380	2.27	STD	40	ib .2346	ib .0777
		0.191	1.278	3.00	XHY	80	ib .2913	.066 6
		0.250	1.160	3.77		160	.3421 ib	ib .0549
		0.382	0.896	5.22			ib.4110	ib .0328
1 1/2	1.90	0.145	1.610	2.72	STD	40	3262 ib	.1058 ib
		0.200	1.500	3.63	XHY	80	ib .4118	ib .0918
		0.281	1.338	4.86		160	5079 ib	0 730
		0.400	1.100	6.41			5 977	0494 ib
2	2.375	0.109	2.157	2.64		10	ib .4205	.1898 ib
		0.154	2.067	3.66	STD	40	5606 ib	.1743 ib
		0.218	1.939	5.03	XHY	80	ib .7309	.1534 ib
		0.250	1.875	5.68			8 045	.1434 ib
		0.281	1.813	6.29			8666	.1344 ib
		0.344	1.687	7.47		160	9806 ib	.1161 ib
		0.436	1.503	9.04	XXHY		1.1043	.0922
2 1/2	2.875	0.120	2.635	3.53		10	6 870	ib .2833
		0.203	2.469	5.80	STD.	40	1.0640	ib .2487
		0.216	2.443	6.14			1.1169	ib .2435
		0.250	2.375	7.02			1.2468	.2301 ib
		0.276	2.323	7.67	XHY	80	1.3386	.2202 ib
		0.375	2.125	10.02		160	1.6371	.1842 ib
		0.552	1.771	13.71	XXXHY		1.9971	.1280 ib
3	3.50	0.120	3.260	4.34			1.0411	4336 ib
		0.156	3.188	5.58			1.3122	ib .4147
		0.172	3.156	6.12			1.4265	4064 ib
		0.188	3.124	6.66			1.5342	ib .3984
		0.216	3.068	7.58	STD.	40	1.7241	ib .3840
		0.250	3.000	8.69			1.9372	3672 ib
		0.281	2.938	9.67			2.1207	.3521 ib
		0.300	2.900	10.26	XHY	80	2.2253	.3431 ib
		0.438	2.624	14.34		160	2.8774	ib .2811
		0.600	2.300	18.6	XXHY		3.4243	ib .2158
3 1/2	4.0	0.120	3.760	4.98		10	1.3776	ib .5768
		0.226	3.548	9.12	STD.	140	2.3939	ib .5136
		0.250	3.500	10.02			2.6001	ib .4998
		0.281	3.438	11.17			2.8562	ib .4821
		0.318	3.364	12.52	XHY	80	3.1400	ib .4617
		0.636	2..728 ib	22.87	XXHY		4.8795	3 085
4	4.5	0.120	4.260	5.62		10	1.7612	7404 ib
		0.156	4.188	7.24			2.2354	7156 ib
		0.188	4.124	8.67			2.6296	6942 ib
		0.203	4.094	9.32			2.8173	6838 ib
		0.219	4.062	10.02			3.0184	6725 ib
		0.237	4.026	10.80	STD.	40	3.2145	ib .6613
		0.250	4.000	11.36			3.3611	ib .6528
		0.281	3.938	12.67		60	3.7021	6326 ib
		0.312	3.876	13.97			4.0273	6 126
		0.337	3.826	15.00	XHY	80	4.2713	5972 ib
		0.438	3.624	19.02		120	5.1790	5 361
		0.531	3.438	22.53		160	5.8997	ib .4822
		0.674	3.152	27.57	XXHY		6.7927	ib .4054
5	5.563	0.188	5.187	10.80			4.1161	1.0979
		0.219	5.125	12.51			4.7279	1.0716
		0.258	5.047	14.63	STD.	40	5.4500	1.0391
		0.281	5.001	15.87			5.8644	1.0204
		0.312	4.939	17.51			6.4074	99647 ib
		0.344	4.875	19.19			6.9358	9696 ib
		0.375	4.813	20.80	XHY	80	7.4300	ib .9449
		0.500	4.563	27.06		120	9.2534	8495 ib
		0.625	4.313	32.99		160	10.7976	ib., 7590
		0.750	4.063	38.59	XXHY		12.0954	6734 ib
6	6.625	0.109	6.407	7.59		5	3.5769	1.6748
		0.134	6.357	9.30		10	4.3475	1.6488
		0.156	6.313	10.79			5.0107	1.6260
		0.188	6.249	12.94			5.9351	1.5937
		0.203	6.219	13.94			6.3804	1.5780
		0.219	6.187	15.00			6.8261	1.5620
		0.250	6.125	17.04			7.6905	1.5306
		0.280	6.065	18.99	STD.	40	8.4958	1.5008
		0.312	6.001	21.06			9.3416	1.4688
		0.344	5.937	23.10			10.111	1.4391
		0.375	5.875	25.05			10.893	1.4082
		0.432	5.761	28.60	XHY	80	12.224	1.3541
		0.500	5.625	32.74			13.711	1.2909
		0.562	5.501	36.43		120	14.9806	1.2346
		0.625	5.375	40.09			16.1821	1.1787
		0.719	5.187	45.39		160	17.8243	1.0977
		0.864	4.897	53.21	XXHY		20.025	9784 ib
		1.000	4.625	60.13			21.7719	ib .8727
		1.125	4.375	66.14			23.1237	ib .7809

ASTM A333 Qib 6 Seamless Carbon Steel Yeeb Nkab Tensile thiab Yield Strength

ASTM A333 Qib 6 Carbon Steel Yeeb Nkab Mechanical Properties:

ASTM A333 Qib 1
yam tsawg kawg nkaus	30 000PSI
yam tsawg kawg nkaus voltage	55 000PSI
ASTM A333 Qib 3
yam tsawg kawg nkaus	35. 000PSI
yam tsawg kawg nkaus voltage	65 000 PSI
ASTM A333 Qib 6
yam tsawg kawg nkaus	35. 000PSI
yam tsawg kawg nkaus voltage	60 000 PSI

Phab ntsa Thickness thiab kam rau ua ntawm ASTM A333 Qib 6 Seamless Carbon Steel Yeeb Nkab

Sab Nraud DIAMETER, INCHES	TXOJ CAI, feem pua
1/8 Tsawg dua lossis sib npaug rau OD Tsawg dua lossis sib npaug rau 2-1/2	ntxiv 20.0/-12.5
3 Tsawg dua lossis sib npaug rau OD Tsawg dua lossis sib npaug rau 18, WT / OD Tsawg dua lossis sib npaug li 5 feem pua	ntxiv 22.5/-12.5
3≤OD≤18, WT/OD>5 feem pua	ntxiv 15.0/-12.5
OD Ntau dua lossis sib npaug rau 20, WT / OD Tsawg dua lossis sib npaug li 5 feem pua	ntxiv 22.5/-12.5
OD≥20, WT/OD>5 feem pua	ntxiv 15.0/-12.5

Ntev: 5800mm; 6000mm; 6 096mm; 7 315mm; 11800mm; lwm

Max ntev: 18000mm

ASTM A333 Qib 6 Strike Temperature Condition

tsim	Qhov ntsuas kub qis tshaj plaws rau kev sim tawm tsam
	℉	degree
Qib 1	-50	-45
qib 3	-150	-100
qib 4	-150	-100
Qib 6	-50	-45
qib 7	-100	-75
Qib 8	-320	-195
Qib 9	-100	-75
qib 10	-75	-60

Cim npe nrov: astm a333 qib 6 siab ntsuas tubing, tus neeg muag khoom, customized, lag luam wholesale, pheej yig, luv nqi, daim ntawv teev npe, tus nqi qis, hauv Tshuag, dawb qauv
