Dab tsi yog qhov sib txawv ntawm 1.4841 thiab 1.4845 stainless hlau?

Puas yog koj tab tom nrhiav rau cov hlau tsis muaj zog rau cov ntawv thov kub? Qib 1.4841 (AISI 310) thiab 1.4845 (AISI 310s) yog cov kev xaiv zoo ua tsaug rau lawv cov oxidation zoo heev thiab thermal ruaj khov. Txawm hais tias ob qho tib si yog cov tsev neeg ntawm anustenitic stainless hlau nrog cov chromium siab (ni) cov ntsiab lus sib txawv, cov cuab yeej siv neeg kho mob thiab cov ntawv thov tshwj xeeb.

Hauv qab no, peb nthuav qhia txhua yam koj yuav tsum paub xaiv cov khoom siv tau, nrog rau GNEE Stainless cov kev muab tshwj xeeb.

Dab tsi yog 1.4841 thiab 1.4845 sib npaug?

Teem nqi	En kev tsim qauv	AISI sib npaug	Tus lej tsis yog	Lub Npe
1.4841	X15crnisi25-21	AISI 310	UNR TSIS YOG S31000	310 Stainless Hlau
1.4845	X8crni25-21	AISI 310s	UNR TSIS YOG S31008	310s stainless hlau (tsis muaj carbon version ntawm 310)

Lwm yam sib luag:

1.4542(Cov nag lossis daus tsis yooj yim, sib npaug rau AISI 630 / 17-4 PH / uns S17400) →Tsis ncaj qha rau 1.4841 / 1.4845, Tab sis tau hais rau nws siv nyob rau hauv cov siab tiv taus thiab corrosion cov ntawv thov.

Qhov sib txawv ntawm 1.4841 thiab 1.4845

1. Tshuaj lom neeg: Lub luag haujlwm ntawm carbon

Ob qib kawm muaj cov chromium siab (24-26%) thiab npib tsib xee (19-22%) cov ntsiab lus, muab lawv oxidation zoo heev thiab kev ruaj ntseg nyob rau hauv thermal ib puag ncig. Lub ntsiab txawv yog nyob hauv cov pa roj carbon (c):

Caij (%)	1.4841 (AISI 310)	1.4845 (AISI 310s)
Carbon (c)	Tsawg dua los yog sib npaug rau 0.20%	Tsawg dua los yog sib npaug rau 0.08% (tsawg dua)
Chromium (cr)	24.0-26.0%	24.0-26.0%
Npib tsib caug (ni)	19.0-22.0%	19.0-22.0%
Silicon (si)	Tsawg dua los yog sib npaug rau 1.5%	Tsawg dua los yog sib npaug rau 1.5%
Manganese (mn)	Tsawg dua los yog sib npaug rau 2.0%	Tsawg dua los yog sib npaug rau 2.0%
Sulphur (s)	Tsawg dua los yog sib npaug rau 0.015%	Tsawg dua los yog sib npaug rau 0.015%
Phosphorus (p)	Tsawg dua los yog sib npaug rau 0.045%	Tsawg dua los yog sib npaug rau 0.045%

1.4845 (310)muaj aCov ntsiab lus ntawm cov roj carbon qis (tsawg dua los yog sib npaug rau 0.08%), UasTxo qhov kev pheej hmoo ntawm cov rhiab (nag lossis daus ntawm carbides ntawm cov ciaj ciam)Thaum lub sij hawm vuam, txhim kho nwsWeldability thiab kuj mus rau intergranular corrosionCov.

1.4841 (310), Nrog ntau dua cov pa roj carbon (tsawg dua los yog sib npaug rau 0.20%), muajmejor resistencia a la oxidación en exposiciones prolongadas a temperaturas extremadamente altas (>1050 Qib)Cov.

Cov Khoom Siv Neeg Kho Tshuab

Ob Qib Muaj Qhov Tseeb Zoo Li Cas (7.9 g /M³), tab sis 1.4841 muaj qhov muaj zog dua li nws cov ntsiab lus carbon ntau dua:

Ntiag tug	1.4841 (310)	1.4845 (310)
Tensile lub zog (mpa)	500-750	500-700
Yield zog (mpa)	Ntau dua los yog sib npaug rau 210	Ntau dua los yog sib npaug rau 200
Elongation (A5,%)	Ntau dua los yog sib npaug rau 40	Ntau dua los yog sib npaug rau 40
Hardness (HB)	Tsawg dua los yog sib npaug rau 215	Tsawg dua los yog sib luag rau 200

Kuj kub thiab kub

Yam tseem ceeb	1.4841 (310)	1.4845 (310)
Qhov kev pabcuam siab tshaj plaws kub (cua)	1100 degrees	1050 degrees
Lub sij hawm luv luv raug	Txog li 1150 degree	Txog 1100 degree
Nce kev tiv thaiv (ntsuas)	Zoo tshaj	Zoo tshaj

Kuj mus rau corrosion thiab oxidation

Ob qib muab cov kev tiv thaiv zoo heev hauv oxidizing ib puag ncig, roj thiab thermal mus.

1.4845 (310s) muaj kev tiv thaiv zoo dua tiv thaiv intergranular corrosion tom qab vuam (ua tsaug rau nws cov pa roj av).

1.4841 (310) Tsis kam rau oxidation thiab scaling zoo dua nyob rau hauv qhuav huab cua saum toj no 1050 degree.

Lub magnetism

Ob qho tib si tsis yog sib nqus nyob rau hauv anealed xeev, tab sis tuaj yeem ua me ntsis sib nqus tom qab ua haujlwm txias (xws li khoov lossis machining).

Tshwj xeeb muab los ntawm gnee stainless

Gnee Stainless tswj cov khoom lag luam loj ntawm 1.4841 thiab 1.4845 daim hlau, tubes thiab tus me nyuam tam sim ntawd.

Khoom Paub meej

Cov nqi: USD 3,200-3,800 rau ntawm tuj (nyob ntawm qhov loj me, ua tiav thiab ntau thiab tsawg).

Yam tsawg kawg nkaus kom muaj nuj nqis (MOQ): 1 tuj (kev cai ntau tshaj plaws muaj).

Lub sij hawm xa tuaj: 7-15 hnub ua haujlwm thoob ntiaj teb.

Ntawv pov thawj: ISO, SGS, BV, en 10204 3.1 / 3.2 (Thib Peb Kev Ntsuam Xyuas Xyuas Xyuas Kev Soj Ntsuam).

Kev Them Nyiaj: T / T, L / C lossis cov kev xaiv hloov tau yooj yim.

Kev Soj Ntsuam Zoo thiab Ntim Khoom Zoo

Kev kuaj nruj ua tau zoo kom ua raws li ASTM, En thiab DIN cov qauv.

Kev ruaj ntseg export ntim (pallets, thawv ntoo, noo noo-resistant qhwv) los tiv thaiv koj cov xaj thaum lub sijhawm thauj mus los.

Ntau qhov ntau thiab tsawg muaj (Tshuag)

Lub cev	Thickness / Inch	Qho ntev	Txoj cai	Ua tiav
Lub tais	3 hli - 100 hli	2000-6000mm	ASTM A240 / EN 10095	No.1 / 2b / polished
Daim ntawv hlau	0.5mm - 6 hli	1000 × 2000mm / 1250 × 2500mm	ASTM A240	BA / 2b / HL / HL
Tus kav dej	1/2 "- 24"	Mus txog 6 meters	ASTM A312 / EN 10216-5	Annealing / Pickling
Kev thaiv qhov rais	6 hli - 300 hli	2 - 6 meters	ASTM A276	Kaj / polished
